DK-02 Single-Motor Two-Stage Electric Standing Desk Frame

Designed for medium and large office furniture wholesalers, DK-02 provides a practical platform for ergonomic workstation ranges, dealer catalogs and corporate furniture packages.

Key Buyer Benefits

• Cost-efficient single-motor architecture for volume sourcing.

• Two-stage columns support seated-to-standing adjustment.

• Three illustrated frame-width positions suit multiple desktop programs.

• Knock-down steel construction supports export packing and warehousing.

• OEM branding, controls, electrical configuration and cartons can be discussed.

Dimensions Shown

• Height: 710–1160 mm

• Frame widths: 885 / 974 / 1047 mm

• Foot length: 600 mm

• Top support: 495 mm

Complete Product Attributes

1. Model: DK-02

2. Category: Electric height-adjustable desk frame

3. Drive: Single motor

4. Column structure: Two-stage / two-section

5. Leg quantity: Two-leg frame

6. Height range: 710–1160 mm

7. Frame-width positions: 885 / 974 / 1047 mm

8. Foot length: 600 mm

9. Top-support length: 495 mm

10. Displayed color: Black

11. Main material: Steel

12. Finish: Powder coated

13. Product form: Frame/base; desktop not shown

14. Desktop compatibility: Rectangular tops, subject to approved drawing

15. Movement: Vertical electric lifting

16. Width adjustment: Multi-position telescopic beam

17. Motor arrangement: One drive for paired columns

18. Control: Wired handset options configurable

19. Memory presets: Optional by controller

20. Anti-collision: Optional by control package

21. Child lock: Optional by handset

22. Soft start/stop: Controller-dependent

23. Overload protection: Controller-dependent

24. Thermal protection: Motor/controller-dependent

25. Lifting speed: Confirm in order specification

26. Rated load: Confirm by approved BOM and test standard

27. Operating noise: Confirm for selected motor package

28. Input voltage: Market-specific option

29. Plug standard: Configurable for destination market

30. Power cable: Supplied as ordered

31. Cable management: Compatible with optional trays and clips

32. Floor interface: Long steel feet with end caps/leveling solution

33. Installation: Knock-down assembly

34. Fastening: Bolt-fastened frame

35. Packaging: Export carton / flat pack

36. Shipping benefit: Efficient container and warehouse use

37. OEM: Logo, label, manual and carton artwork available

38. ODM: Color, control and electrical options configurable

39. MOQ: Quotation-based

40. Sample: Subject to confirmation

41. Lead time: Based on quantity and schedule

42. Quality control: Function and pre-shipment checks available

43. Documentation: Supplied as contracted

44. Warranty: Defined in sales agreement

45. Environment: Indoor office and study use

46. Ergonomic purpose: Seated-to-standing transitions

47. Target buyer: Medium and large office furniture wholesalers

48. Applications: Open offices, showrooms and corporate workstations

49. Sales channel: B2B wholesale and contract furniture catalogs

50. Core advantage: Cost-controlled scalable single-motor platform

Trade Notice

Final load, speed, noise, electrical package, certifications, desktop range, packaging, MOQ, lead time and warranty must be confirmed in the approved quotation and order specification.
